FIREWALL PANEL
Specially crafted 2″–3″ AAC panels for firewall applications.
FIREWALL PANEL
Specially crafted 2″–3″ AAC panels for firewall applications.
Standard sizes: 2″–3″ thick, 2’x4′ to 2’x10′.
Firewall Panel
ADVANTAGES
- Fast installation during framing, with no need for specialized labor.
- Complies with a 2 – 3 hour fire rating.
- Highly acoustic, achieving a 58 STC rating.
APPLICATION
- Sound absorbing 2 hour Firewalls, Shaftwalls, Area Separation Walls, Demising Walls, Party Walls.
WEIGHT
- 5.12–7.68 lbs/ft²
LITECON Firewall Panel VS Others
LITECON - FIREWALL
SHAFTLINER SYSTEM
Higher Quality - Faster Installation - Lower Cost
- LITECON FIREWALL
- SHAFTLINER
Features/Systems |
 LITECON FIREWALL |
 SHAFTLINER |
| Superior Sound Insulation | ✔ | ✖ |
| Cost-Efficient | ✔ | ✖ |
| Quick and Easy Installation | ✔ | ✖ |
| No H-Studs Required | ✔ | ✖ |
| No C-Tracks Necessary | ✔ | ✖ |
| Zero Shortages | ✔ | ✖ |
| No Specialized Labor Needed | ✔ | ✖ |
